Small openable clamp current transformers with round apertures from 10mm to 50mm, giving mA or 333mV outputs for smart meters, sub-metering and IoT energy monitoring.
Lead time: 8 - 10 days
Models in this range:
K-P10 – 10mm aperture, 5A/1.67mA to 80A/26.7mA, class 0.5
K-P10-333mV – 10mm aperture, (5-50)A/333mV, class 1
K-P10N – 10mm aperture, 5A/1.25mA to (40-60)A/20mA, class 0.5
K-P16 – 16mm aperture, 120A/40mA, (40-100)A/20mA, 80A/32mA, class 0.5
K-P16-333mV – 16mm aperture, (40-100)A/333mV, class 0.5
K-P16N – 16mm aperture, (20-50)A/10mA to 100A/40mA, class 0.5
K-P16-M – 16mm aperture, 20-120A/50mA, class 0.5
K-P24 – 24mm aperture, 60-200A/20mA, 200A/40mA, or 150-300/5(1)
K-P24-333mV – 24mm aperture, (60-200)A/333mV, class 0.5
K-P24N – 24mm aperture, (60-100)A/20mA to 400A/100mA, class 0.5
K-P24-A – 24mm aperture, (150-300)A/5A, class 1-1.5
K-P24-B – 24mm aperture, (150-300)A/1A, class 1-1.5
K-P24-M – 24mm aperture, (100-300)A/40mA, class 0.5
K-P36 – 36mm aperture, 400A/50mA, 600A/75mA, 200-400A/20mA, or 300-600/5(1)
K-P36-333mV – 36mm aperture, (100-600)A/333mV, class 0.5
K-P36N – 36mm aperture, (200-400)A/20mA to 400A/40mA, class 0.5
K-P50 – 50mm aperture, 600-700/5(1), 800-900/5(1), 1000/5(1)
Select your model from the dropdown above. Prices include VAT.
